SYOGM Trommel Wash Plant 15 tonnes per hour, back view in the field


SYOGM Trommel Wash Plant 15 tonnes per hour, back view in the field
===================================================================









SYOGM Trommel Wash Plant 15 tonnes per hour, back view in the field



SYOGM Trommel Wash Plant 15 tonnes per hour, back view in the field




Based on the image provided, here is a description in the context of the **SYOGM Trommel Wash Plant (15 tonnes per hour), back view in the field**:

**Subject and Function:**
The image displays a **SYOGM Trommel Wash Plant**, specifically a compact, mobile unit designed for processing raw materials like sand, gravel, or mineral ore. The "15 tonnes per hour" specification indicates its throughput capacity, making it suitable for small-scale mining, construction, or aggregate production where portability and efficiency are key.

**Structural Features (Back View):**
* **Red Steel Frame:** The entire machine is painted a vibrant red and constructed from heavy-duty steel beams and supports. The frame is designed to be robust yet lightweight enough for transport.
* **Inlet Hopper:** At the top rear, there is a large, trapezoidal hopper designed to receive raw material. Its wide opening facilitates easy feeding, while the internal structure (visible through the open back) suggests a design to guide material efficiently into the trommel drum below.
* **Trommel Drum:** The central cylindrical component (partially visible beneath the hopper) is the core of the wash plant. It rotates to screen and wash the material as it tumbles inside.
* **Hydraulic/Pump System:** On the lower left side, a black pump unit is visible, connected by hoses and pipes. This is likely the water pump essential for the washing process, circulating water to clean the aggregate.
* **Skid Base:** The machine sits on a sturdy, rectangular skid base with outriggers or feet (visible at the bottom corners) to stabilize it during operation.

**Field Context:**
* **Environment:** The wash plant is situated in a dry, arid landscape with reddish-brown soil, typical of regions where mining or construction aggregate is extracted.
* **Vegetation:** Sparse acacia trees and dry grass surround the machine, indicating a rural or remote operational site.
* **Operational Readiness:** The machine appears to be in an operational or standby position in the field, ready for processing raw materials directly from the site. The clean condition of the paint and components suggests it is either new or well-maintained.
